Micro CAF K-1

Micro CAF K-1

Thông số kỹ thuật CAF K-1:
1. Frequency range: 640-690MHz
2. Modulation method: FM
3. Number of channels: 2 * 100
4. Channel blocking: 450KHz
5. Frequency stability: ± 0.005%
6. Dynamic range: 100dB
7. Maximum offset: ± 45KHz
8. Audio frequency response: 60Hz-18KHz (± 3dB)
9. Comprehensive signal-to-noise ratio:> 105dB
10. Comprehensive distortion: ≤0.5%
11. Working environment temperature: -10C-+ 50C
Receiver parameter technology:
1. IF: 110MHz. 10.7MHz
2. Antenna access: BNC / 50Ω
3. Sensitivity: 12dBuV (80db S / N)
4. Sensitivity adjustment range: 12-32dBuV
5. Spurious suppression: ≥75dB maximum output level: + 10dBv

Transmitter parameter technology:
Type: 2 x dynamic
Hand-held antenna: integrated
RF output: 10mW-30mW
Maximum deviation: ± 25kHz
Battery: 2 1.5V AA per microphone
Battery life: 6-8 hours
