LVP8601 MULTI-WINDOWS SYNC PROCESSOR
9.000.000₫
- Xuất xứ: Chính Hãng
- Thương hiệu: KYSTAR
- Chiều cao: 89 mm
- Chiều rộng: 300 mm
- Chiều sâu : 482.6 mm
- Trọng lượng: 5 kgs
- Bảo hành: 1 Năm
chọn mua:
Mua hàng
sản phẩm gợi ý
Features
1. An all-in-one processor integrating mix matrix switching, pixel-to-pixel sync mosaic and multi-display
2. Inputs: HD+SD, analog+digital, totally 16 inputs including: CVBS x 4, VGA x 4, DVI x 4, SDI / HD-SDI x 4
3. Outputs: 8 DVI FULL HD digital outputs, each with maximal resolution up to 1920 x 1080@60Hz
4. Synchronous mosaic technology: to realize mosaic processing of ultra HD video displayed by multi-display graphics card or networking player
5. Supports zoom mosaic or pixel-to-pixel mosaic, single unit can maximumly support horizontal 15360 pixels or vertical 8640 lines
6. 4-picture preview output
7. 4K2K ultra high-definition dynamic background picture
8. Adopting crosspoint high bandwith and high daterate transmission technology
9. State-of-the-art motion adaptive de-interlacing technology: to eliminate trailing or jaggies of motion pictures
10. Seamless switching or fade-in / fade-out switching between any two input signals
11. Image and text overlap supported, AIAO ( Any In Any Out ) allows for displaying any captured picture in any specific area on screen
12. Multiple pre-saved modes supported, Seamless switching or fade-in / fade-out switching between different modes
13. Convenient panel / RS232 / USB / LAN control and setup
Specifications
| Inputs | ||
| Quantity / Type | 4 x Video | |
| Video System | PAL / NTSC | |
| Composite video | 1V（p_p）/ 75Ω | |
| VGA Format | PC( VESA ) | ≤1920 x 1080@60Hz |
| VGA Amplutide Impedance | R、G、B = 0.7 V（p_p）/ 75Ω | |
| DVI Format | PC ( VESA ) | ≤1920 x 1080@60Hz |
| HDMI-1.3（CEA-861） | ||
| SDI / HD-SDI / | SMPTE 259M | 480i @60Hz |
| Input connectors | Video：VGA | |
| Outputs | ||
| Quantity / Type | 8 x DVI | |
| Preview Output | 1×DVI（Out-K or Out-L） | |
| DVI Format | 1024×768@60Hz | |
| Output connectors | DVI：24+1 DVI_D | |
| Others | ||
| Control | RS232 / USB / LAN | |
| Input Voltage | 100-240VAC 50 / 60Hz | |
| Consumption | ≤100W | |
| Environment temperature | 0-45 ℃ | |
| Environment Humidity | 15-85% | |
| Size | 482.6 ( Length ) x 300 ( Width ) x 89 ( Height )mm | |
| Gross weight | 9Kg | |
| Net weight | 5Kg | |
| Kích thước | Chiều cao | 89 mm |
| Chiều rộng | 300 mm | |
| Chiều sâu | 482.6 mm | |
| Trọng lượng | 5 kgs | |
| Nguồn điện | AC 100-240V | 50/60Hz |
| Công suất | 100W | |
| Màu Sắc | Đen | Trắng |
